Uniview

8MP LightHunter 36X PTZ Security Camera with Smart Intrusion Prevention | IPC568EB-DGK-I0

IPC568EB-DGK-I0

  • • High quality image with 6MP Progressive CMOS sensor for ultra-clear surveillance. • Motorized varifocal lens provides flexible viewing and precise remote zoom adjustment. • Supports Ultra 265, H.265, H.264, and MJPEG video compression. • LightHunter technology delivers exceptional image quality in low-light environments. • AI-powered perimeter protection with human and vehicle classification for accurate event detection. • 130dB True WDR ensures clear images in high-contrast lighting conditions. • Built-in microphone and speaker for two-way audio communication. • Smart IR illumination for reliable night vision performance. • Supports MicroSD card up to 512GB for edge storage. • IP67 weatherproof and IK10 vandal-resistant housing for demanding outdoor installations.
🛡️

5-Year Warranty

Industry-leading coverage

🚚

Free Shipping

On orders over $99

🛡️

NDAA Compliant

Approved products

↩

30-Day Returns

Hassle-free returns

$249.00 USD
$249.00 USD
Sale Sold out
🛒 Request Quote
⇄ Compare ♡ Wishlist
🗂 Get Free System Design 🎧 Talk to an Expert
🔒

Secure Checkout Guaranteed

256-bit SSL encrypted

Visa Mastercard American Express Discover Shop Pay Apple Pay Google Pay
  IPC568EB-DGK-I0
Camera
Sensor 1/1.8" CMOS
Min. Illumination Color: 0.002 Lux (F1.2, AGC ON), BW: 0.0002 Lux (F1.2, AGC ON)
Day/Night IR-cut filter with auto switch (ICR)
Shutter Auto/Manual, 1 to 1/100000 s
WDR 120 dB
S/N >56 dB
Lens
ABF Support
Lens Mount C/CS
Iris Type DC-iris/P-iris
Video
Video Compression Ultra 265, H.265, H.264, MJPEG
Video Bit Rate 128 Kbps to 16 Mbps
U-code Support
ROI Support
Video Stream Triple streams
Privacy Mask Up to 4 areas
OSD Up to 10 OSDs
Frame Rate-Main Stream 8 MP (3840 × 2160), max. 30 fps
Frame Rate-Sub Stream 720P (1280 × 720), max. 30 fps
Frame Rate-Third Stream D1 (720 × 576), max. 30 fps
Intelligent
Exception Detection Object removed, Object Left Behind, Scene change
Smart Intrusion Prevention Cross line detection, intrusion detection, enter area detection, leave area detection (support false alarm filtering and the classification of human, non-motor vehicle and vehicle)
People Counting Support people flow counting and crowd density detection
Road Traffic Support capturing car license picture when the car passes tripwire, Up to 4 lanes can be set, Two types of application mode avaliable: High/Low pole
White Balance Auto, Outdoor, Fine tune, Sodium lamp, Locked, Auto2
Digital Noise Reduction 2D/3D DNR
Flip Normal, Flip vertical, Flip horizontal, 180°
HLC Support
BLC Support
Defog Digital defog, Optical defog
Heatwave Reduction N/A
Events
Basic Detection Motion detection, Tampering alarm, Audio detection, Object removed, Object Left Behind, Scene change
General Function Watermark, IP address filtering, Access policy, ARP protection, RTSP authentication, User authentication, HTTP authentication, Alarm input, Alarm output
Audio
Audio Compression G.711U, G.711A
Audio Bitrate 128 Kbps
Two-way Audio Support
Suppression Support
Sampling Rate 16KHZ
Storage
Edge Storage MicroSD, up to 512 GB
Network Storage ANR, NAS (NFS)
Network
Protocols SSH, IGMP, RTP, RTCP, SMTP, IPv4, IPv6, ICMP, ARP, TCP, UDP, DHCP, PPPoE, RTSP, RTMP, DNS, DDNS, NTP, FTP, UPnP, HTTP, HTTPS, 802.1x, SNMP, QoS, SSL/TLS
Compatible Integration ONVIF (Profile S, Profile G, Profile T, Profile M), API, SDK
User/Host Up to 32 users. 3 user levels: administrator, common user and operator
Security TLS 1.3, Password Protection, Strong Password, HTTPS Encryption, Export Operation Logs, Basic and Digest Authentication for RTSP, Digest Authentication for HTTP, TLS 1.2, WSSE and Digest Authentication for ONVIF
Client EZStation, UNV-Link, UNV-Link Pro
Web Browser Plug-in required live view: IE 10+, Chrome 45+, Firefox 52+, Edge 79+, Plug-in free live view: Chrome 57+, Firefox 58+, Edge 16+
Interface
Audio I/O 1 Input: impedance 1 kΩ, amplitude 2.5 V [p-p], 1 Output: impedance 600 Ω, amplitude 2.5 V [p-p]
Alarm I/O 2/1
Serial Port 1 × RS485
Network 1 × RJ45 10 M/100 M/1000 M Base-TX Ethernet + 1 × 100 M/1000 M SFP
Video Output 1 BNC (for debugging)
Certification
EMC CE-EMC (EN 55032: 2015+A1:2020,EN 61000-3-3: 2013+A1: 2019,EN IEC 61000-3-2: 2019+A1: 2021,EN 55035: 2017+A11:2020)
FCC (FCC CFR 47 part15 B, ANSI C63.4-2014)
Safety CE LVD (EN 62368-1:2014+A11:2017)
UL (UL 62368-1, 2nd Ed., Issue Date: 2014-12-01)
Environment CE-RoHS (2011/65/EU;(EU)2015/863); WEEE (2012/19/EU); Reach (Regulation (EC) No 1907/2006)
General
Power DC 12 V (±25%), AC 24 V (±25%), PoE (IEEE 802.3af)
Power Consumption Max. 8 W
Power Interface Two-core terminal block
Dimensions 152 mm × 71 mm × 65 mm (6.0" × 2.8" × 2.6") (L × W × H) (excluding the lens)
Weight 0.40 kg (0.88 lb)
Working Environment -20 ℃ to 60 ℃ (-4 ℉ to 140 ℉), Humidity: ≤ 95% RH (non-condensing)
Storage Environment -40 ℃ to 70 ℃ (-40 ℉ to 158 ℉), Humidity: ≤ 95% RH (non-condensing)
Surge Protection 6 KV
Reset Button Support
Web Client Language 22 Languages: Traditional Chinese, English, Simplified Chinese, Polish, German, Russian, French, Korean, Dutch, Czech, Portuguese (Europe), Portuguese (Brazil), Japanese, Thai, Turkish, Spanish (Latin America), Spanish (Europe), Hungarian, Italian, Vietnamese, Arabic, Slovak
Configurable
P/N Support
