Uniview

2MP Fixed Bullet Camera | IPC2128SB-ADF28KM-DL-I1

IPC2128SB-ADF28KM-DL-I1

  • • High quality image with 8MP Progressive CMOS sensor. • 2.8mm fixed lens with intelligent Dual-Light technology. • Supports Ultra 265, H.265, H.264, and MJPEG compression. • ColorHunter delivers vivid 24/7 full-color surveillance. • AI-powered Smart Intrusion Prevention with human and vehicle classification. • Built-in microphone and speaker for two-way audio. • Smart IR and warm white light illumination. • Supports MicroSD cards up to 512GB. • IP67 weatherproof and IK10 vandal-resistant protection.
🛡️

5-Year Warranty

Industry-leading coverage

🚚

Free Shipping

On orders over $99

🛡️

NDAA Compliant

Approved products

↩

30-Day Returns

Hassle-free returns

$699.00 USD
$699.00 USD
Sale Sold out
🛒 Request Quote
⇄ Compare ♡ Wishlist
🗂 Get Free System Design 🎧 Talk to an Expert
🔒

Secure Checkout Guaranteed

256-bit SSL encrypted

Visa Mastercard American Express Discover Shop Pay Apple Pay Google Pay
  IPC2128SB-ADF28KM-DL-I1 IPC2128SB-ADF40KM-DL-I1
Camera
Max Resolution 8 MP
Sensor 1/2.7" CMOS
Min. Illumination Color: 0.002 Lux (F1.6, AGC ON), 0 Lux with light
Day/Night IR-cut filter with auto switch (ICR)
Shutter Auto/Manual, 1 to 1/100000 s
Adjustment Angle Pan: 0° to 360°, Tilt: 0° to 90°, Rotate: 0° to 360°
S/N > 52 dB
WDR 120 dB
Lens
Focal Length 2.8 mm 4.0 mm
Iris F1.6
Field of View (H) 90° 112.1°
Field of View (V) 48.6° 64.8°
Field of View (D) 106.7° 124.3°
Lens Type Fixed
Iris Type Fixed
DORI
DORI Distance (Lens) 2.8 mm 4.0 mm
DORI Distance (Detect) 84.0 m (275.6 ft.) 120.0 m (393.7 ft.)
DORI Distance (Observe) 33.6 m (110.2 ft.) 48.0 m (157. 5 ft.)
DORI Distance (Recognize) 16.8 m (55.1 ft.) 24.0 m (78.7 ft.)
DORI Distance (Identify) 8.4 m (27.6 ft.) 12.0 m (39.4 ft.)
Illuminator
Illumination Distance (Warm Light) 40 m (131.2 ft)
Illumination Distance (IR) 40 m (131.2 ft)
Wavelength 850 nm
Light On/Off Control Auto/Manual
Video
Video Compression Ultra 265, H.265, H.264, MJPEG
H.264 Code Profile Baseline profile, Main profile, High profile
Frame Rate Main Stream: 8 MP (3840 × 2160), max. 25 fps; 5 MP (3072 × 1728), max. 30 fps; 4 MP (2560 × 1440), max. 30 fps; 1080P (1920 × 1080), max. 30 fps;720P (1280 × 720), max. 30 fps;
Sub Stream: 1080P (1920 × 1080), max. 30 fps; 720P (1280 × 720), max. 30 fps; D1 (720 × 576), max. 30 fps; 640 × 360, max. 30 fps; 2CIF (704 × 288), max. 30 fps; CIF (352 × 288), max. 30 fps;
Third Stream: D1 (720 × 576), max. 30 fps; 640 × 360, max. 30 fps; 2CIF (704 × 288), max. 30 fps; CIF (352 × 288), max. 30 fps
Video Bit Rate 128 Kbps to 16 Mbps
U-code Support
OSD Up to 8 OSDs
Privacy Mask Up to 4 areas
ROI Support
Video Stream Triple streams
White Balance Auto, Outdoor, Fine tune, Sodium lamp, Locked, Auto2, Area white balance
Smart IR Support
Digital Noise Reduction 2D/3D DNR
Flip Normal, Flip vertical, Flip horizontal, 180°, 90° Clockwise, 90° Anti-clockwise
Dewarping Support
HLC Support
Low Illumination Characteristics ColorHunter with Wise-ISP
BLC Support
Defog Digital defog
Intelligent
Smart Intrusion Prevention Cross line detection, intrusion detection, enter area detection, leave area detection (support false alarm filtering and the classification of human, non-motor vehicle and vehicle)
People Counting Support people flow counting and crowd density detection
Events
Basic Detection Motion detection, Ultra motion detection, Tampering alarm, Audio detection
General Function Watermark, IP address filtering, Access policy, ARP protection, RTSP authentication, User authentication, HTTP authentication
Audio
Audio Compression G.711U, G.711A, AAC-LC
Audio Bitrate G.711U/G.711A: 64 kbps, AAC-LC: 128 kbps
Two-way Audio N/A
Suppression Support
Sampling Rate G.711U/G.711A: 8 kHz, AAC-LC: 8 kHz, 16 kHz, 48 kHz
Storage
Edge Storage MicroSD, up to 512 GB
Network Storage ANR, NAS (NFS)
Network
Protocols IGMP, SMTP, IPv6, ICMP, ARP, TCP, UDP, DHCP, PPPoE, RTSP, DNS, DDNS, NTP, UPnP, HTTP, 802.1x, SNMP, SSL/TLS, IPv4, RTP, RTCP, RTMP, HTTPS, FTP
Compatible Integration ONVIF (Profile S, Profile G, Profile T, Profile M), API, SDK
User/Host Up to 32 users. 2 user levels: administrator and common user
Security Password protection, Strong Password, HTTPS encryption, Export operation logs, Basic and Digest Authentication for RTSP, Digest Authentication for HTTP, TLS 1.2, WSSE and Digest Authentication for ONVIF, DTLS 1.2
Client EZStation, APP
Web Browser Plug-in required live view: IE 10+, Chrome 45+, Firefox 52+, Edge 79+, Plug-in free live view: Chrome 57+, Firefox 58+, Edge 16+
Interface
Audio I/O N/A
Alarm I/O N/A
Serial Port N/A
Built-in Mic Support
Built-in Speaker N/A
WIFI N/A
Network 1 × RJ45 10 M/100 M Base-TX Ethernet
Video Output N/A
Certification
EMC CE-EMC (EN 55032, EN 61000-3-3, EN IEC 61000-3-2, EN 50130-4)
FCC (FCC 47 CFR part15 B)
Safety CE-LVD (EN 62368-1)
UL/CUL (UL 62368-1, CAN/CSA C22.2 No. 62368-1)
Environment CE-RoHS (2011/65/EU ; (EU) 2015/863) ; WEEE (2012/19/EU)
Protection IP67 (IEC 60529)
General
Power DC 12 V±25%, PoE (IEEE 802.3af)
Power Consumption Max. 6.3 W
Power Interface Ø5.5 mm coaxial power plug
Dimensions 156.4 mm × 63.1 mm × 62.7 mm (6.2" × 2.5" × 2.5") (L × W × H)
Weight 0.43 kg (0.95 lb)
Working Environment -30 ℃ to 60 ℃ (-22 ℉ to 140 ℉), Humidity: ≤ 95% RH (non-condensing)
Storage Environment -30 ℃ to 60 ℃ (-22 ℉ to 140 ℉), Humidity: ≤ 95% RH (non-condensing)
Surge Protection 4 KV
Reset Button Support
Web Client Language 20 Languages: Traditional Chinese, English, Simplified Chinese, Polish, German, Russian, French, Korean, Dutch, Czech, Portuguese (Europe), Portuguese (Brazil), Japanese, Thai, Turkish, Spanish (Latin America), Spanish (Europe), Hungarian, Italian, Vietnamese
